Overview

opal, the open population assessment library, is an open-source, modular R package for fisheries stock assessment. It is built on RTMB, which provides automatic differentiation of the objective function, gradient-based optimisation, and the Laplace approximation for random effects. The full model is written in R, so it can be read, modified, and extended without working in C++.

opal builds on the sbt package developed by Quantifish for the CCSBT southern bluefin tuna assessment, and draws on design elements from SS3, MULTIFAN-CL, WHAM, SPoRC, and CASAL2. It is being developed in support of WCPFC Project 123: Scoping the next generation of tuna stock assessment software.

Development status: opal is under active development. Case studies are illustrative and are not intended to inform management advice. Interfaces may change between versions.

Resources

Resource Contents
Project website Project background, development plan and governance, the WCPFC SC22 working paper and presentation, and the ’opakapaka case study
Development documentation The dev object workflow, function reference, vignettes, and changelog
Release documentation Documentation published from main
opal-documentation Quarto source for the project website and WCPFC documents
Issues Bug reports, feature requests, and development discussion

Features

  • Population dynamics: Age- and season-structured dynamics conditioned on observed catch (in weight or numbers). Seasonal harvest rates are solved from catch and vulnerable abundance, with a posfun() penalty that keeps total harvest below one. Beverton–Holt recruitment with log-normal deviates and SS3-style bias-adjustment ramps, fished or unfished initial equilibrium, and static and dynamic depletion.
  • Growth and biology: von Bertalanffy growth (L1/L2/k), optionally with SS3 GrowthModel 3 cumulative age-specific K multipliers and its plus-group length approximation (Methot and Wetzel 2013), with variability in length at age represented as a probability-of-length-at-age matrix. Maturity, weight, and fecundity can be supplied at age or at length; length-based inputs are converted on the AD tape so gradients propagate when growth is estimated.
  • Selectivity: Logistic, double-normal, double-Richards, and length-based forms, with helpers to convert between SS3 and opal selectivity parameterisations.
  • Data and likelihoods: Log-normal CPUE with multiple indices; length and weight compositions with multinomial, Dirichlet, or Dirichlet-multinomial likelihoods (weight compositions are predicted by rebinning from length); and user-specified priors.
  • Estimation and diagnostics: Fit an opal_obj with opal_fit() and check it with opal_check(); estimability checks, correlated-parameter detection, and parameter tables (check_estimability(), get_cor_pairs(), get_par_table()). Observations are marked with RTMB’s OBS(), which supports simulation with obj$simulate() and one-step-ahead residuals.
  • Bayesian inference: No-U-turn sampling with SparseNUTS through opal_mcmc(assessment), which manages the runtime, worker dependencies, bounds, and sample storage.
  • Projections: Forward projections of dynamics, recruitment deviations, and selectivity (project_dynamics(), project_rec_devs(), project_selectivity()).
  • Portable assessment objects: One opal_obj stores configuration, fitted parameters, optimiser output, MCMC draws, diagnostics, derived results, and provenance throughout the assessment lifecycle. RTMB objectives are rebuilt on demand.

Case studies

  • ’Opakapaka (Pristipomoides filamentosus): a fixed-effects assessment benchmarked against its SS3 reference model. It is the basis for the Quickstart vignette, the bundled example fit, and the package’s numerical regression and simulation self-tests.
  • WCPO bigeye tuna (Thunnus obesus): a high-dimensional quarterly assessment (15 fisheries, 40 age classes, length and weight compositions) compared against SS3 and MULTIFAN-CL. Development workflows are in dev/vignettes/.

Both case studies are described in the SC22 working paper on the project website.

Installation

Install the development version of opal from GitHub:

# install.packages("remotes")
remotes::install_github("N-DucharmeBarth-NOAA/opal@dev")

opal depends on SparseNUTS, which is not on CRAN. If installation fails because SparseNUTS is unavailable, install StanEstimators first (preferably in a fresh R session):

install.packages(
  "StanEstimators",
  repos = c("https://andrjohns.r-universe.dev", "https://cloud.r-project.org")
)

Then install SparseNUTS and retry the opal installation:

remotes::install_github("noaa-afsc/SparseNUTS")

For development, the package environment is pinned with renv; run renv::restore() from the repository root.

Quick start

Fit the bundled ’opakapaka example using one portable opal_obj. The full walkthrough is in the Quickstart guide (or vignette("quickstart") when installed with vignettes).

library(opal)
inputs <- opaka_quickstart_inputs()
assessment <- opal_obj(inputs$data, inputs$parameters, inputs$map,
                       metadata = list(stock = "Opakapaka"))
assessment <- opal_fit(assessment)
summary(assessment)
plot_cpue(assessment)

The fitted stage records a completed optimisation; check assessment$validation$fit for convergence, gradients, Hessian, bounds, and population checks. Diagnostics warn and retain the results when checks fail.

Sampling, saving, and updating

assessment <- opal_mcmc(assessment, seed = 42)
summary(assessment)
opal_save(assessment, "assessment.rds")
assessment <- opal_read("assessment.rds")
report <- opal_report(assessment)

Sampling can also start without fitting. It uses an isolated runtime, records settings and diagnostics, and preserves previous attempts in mcmc_history. A failed or unchecked attempt does not replace a checked, passing posterior. Short sampler runs are useful software checks, not evidence of convergence. opal_as_tmbfit(assessment) supports existing SparseNUTS diagnostics.

Save and read work at every lifecycle stage. Files contain portable R data, a checksum, and scientific model metadata. Reading never optimises or samples. opal_rtmb(assessment, fresh = TRUE) provides an isolated runtime for advanced work.

Use opal_update() to change configuration. Data, priors, parameters, maps, random effects, and bounds invalidate dependent results. Metadata and optimiser controls do not. An unchanged-model refit preserves the posterior and its original fit provenance. Projections accept assessment objects; opal_project() stores results with their source identity. Choose mcmc or mvn uncertainty explicitly when posterior draws exist. Random-effect projections require complete joint posterior draws.

Existing fits

The legacy opal_fit(data, obj, opt, ...) constructor and two-input plotting calls remain supported. Use opal_from_fit(old_fit) to adopt the staged workflow. opal_read() also upgrades saved legacy files, verifying the rebuilt objective across R versions without refitting:

assessment <- opal_read(
  system.file("extdata", "opaka_quickstart_fit.rds", package = "opal")
)

See the saved-fit review and projection guide for complete object-based examples.

Contributing

Contributions are welcome. Please read CONTRIBUTING.md before opening a pull request. In brief:

  • Open an issue to discuss substantial changes before starting work.
  • Submit pull requests against the dev branch; main is the stable release branch.
  • Any change that alters model numerics must follow the regeneration protocol described in CONTRIBUTING.md: show the golden test failing, document the change in NEWS.md, bump .opal_model_scientific_version, and regenerate the test reference and bundled example fit.

License

opal is released under the GNU General Public License, version 3 or later. See the GPL licence.

Citation

A formal package citation is not yet available. In the meantime, please cite the WCPFC SC22 working paper describing opal, available from the project website.
